Yeah, we ride sleds. That’s why the facts point to a better, more thought-out snowmobile trailer. More room for securing and riding in/out, rugged construction, smart aesthetics, snowmobiler-friendly standards and options, and Stealth’s quality reputation is what you’ll be riding on.

Scroll to the right to see more trailer sizes »

7 X 17 TA7 X 19 TA7 X 21 TA7 X 23 TA7 X 25 TA7 X 27 TA7 X 29 TA8.5 X 17 TA8.5 X 19 TA8.5 X 21 TA8.5 X 23 TA8.5 X 25 TA8.5 X 27 TA8.5 X 29 TA
Overall Length19′-3″21′-3″23-3″25-3″27-3″29′-3″31′-3″19′-3″ Overall Length 21′-3″23′-3″25′-3″27′-3″29′-3″31′-3″
Overall Width102″102″102″102″102″102″102″102″ Overall Width 102″102″102″102″102″102″
* Overall Height7′-10″7′-10″7′-10″7′-10″7′-10″7′-10″7′-10″8′-9″ * Overall Height 8′-9″8′-9″8′-9″8′-9″8′-9″8′-9″
** Platform Height20″20″20″20″20″20″20″29 1/2″ ** Platform Height 29 1/2″29 1/2″29 1/2″29 1/2″29 1/2″29 1/2″
Interior Height6′-0″6′-0″6′-0″6′-0″6′-0″6′-0″6′-0″6′-0″ Interior Height 6′-0″6′-0″6′-0″6′-0″6′-0″6′-0″
Interior Overall Length16′-7″18′-7″20′-7″22′-7″24′-7″26′-7″28′-7″16′-7″ Interior Overall Length 18′-7″20′-7″22′-7″24′-7″26′-7″28′-7″
Interior Width80″80″80″80″80″80″80″96″ Interior Width 96″96″96″96″96″96″
Between Wheel WellsN/AN/AN/AN/AN/AN/AN/AN/A Between Wheel Wells N/AN/AN/AN/AN/AN/A
Side DoorStandardStandardStandardStandardStandardStandardStandardStandard Side Door StandardStandardStandardStandardStandardStandard
Side Door W x H24″ x 68″36″ x 68″36″ x 68″36″ x 68″36″ x 68″36″ x 68″36″ x 68″48″ x 68″ Side Door W x H 48″ x 68″48″ x 68″48″ x 68″48″ x 68″48″ x 68″48″ x 68″
Rear DoorRampRampRampRampRampRampRampRamp Rear Door RampRampRampRampRampRamp
Rear Door W x H78″ x 68 1/2″78″ x 68 1/2″78″ x 68 1/2″78″ x 68 1/2″78″ x 68 1/2″78″ x 68 1/2″78″ x 68 1/2″94″ x 73 1/2″ Rear Door W x H 94″ x 73 1/2″94″ x 73 1/2″94″ x 73 1/2″94″ x 73 1/2″94″ x 73 1/2″94″ x 73 1/2″
Tongue Weight163176191206212218227164 Tongue Weight 176191217242255267
Ball Size2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″ Ball Size 2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″2 5/16″
G.A.W.R. (Each Axle)35003500350035003500350035003500 G.A.W.R. (Each Axle) 350035003500350035003500
G.V.W.R.69906990699069906990699069906990 G.V.W.R. 699069906990699069906990
Curb Weight13601466158817201770182018881365 Curb Weight 147015901805202021232225
Average Payload Capacity56305524540252705220517051025625 Average Payload Capacity 552054005185497048674765
BrakesElectricElectricElectricElectricElectricElectricElectricElectric Brakes ElectricElectricElectricElectricElectricElectric
Axles4″ Drop Spring4″ Drop Spring4″ Drop Spring4″ Drop Spring4″ Drop Spring4″ Drop Spring4″ Drop SpringStraight Spring Axles Straight SpringStraight SpringStraight SpringStraight SpringStraight SpringStraight Spring
TiresST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRC Tires ST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRCST205/75R15 LRC
WheelsSilver ModSilver ModSilver ModSilver ModSilver ModSilver ModSilver ModSilver Mod Wheels Silver ModSilver ModSilver ModSilver ModSilver ModSilver Mod
Frame2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube Frame 2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube2″ x 5″ Tube
Floor3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax Floor 3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax3/4″ Drymax
Walls24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only Walls 24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only24″ Kickboard only
CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud Ceiling Ceiling Open Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud CeilingOpen Stud Ceiling
Floor Crossmembers24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube Floor Crossmembers 24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube
Wall Posts16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube Wall Posts 16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube16″ O/C Tube
Roof Bows24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube Roof Bows 24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube24″ O/C Tube

* Note: Overall height does not include roof vents or A/C. Please add 4″ for roof vents & 13″ for A/C’s.

** Note: Platform Height drops 4″ with 48″ beavertail and drops 5″ with 72″ beavertail.

STANDARD FEATURES

  • 2″ x 5″ Double Hollow Tube Alu 6061/T-6 Main Frame (17′ TO 30′)
  • 2″ x 6″ Double Hollow Tube Alu 6061/T-6 Main Frame (31′ Model)
  • Integrated A-Frame on 7′ Wide models
  • 24″ O/C Tube Aluminum Crossmembers
  • 16″ O/C Tube Aluminum Wall Posts
  • 24″ O/C Tube Aluminum Roof Bows
  • Lippert Spring Axle w/4″ Drop
  • Silver Modular Steel Wheels w/ Radial Tires and Chrome Center Caps
  • Radial Tires
  • Wide Track Axles on 7Wide
  • Deck Over on 8.5x
  • Electric Brakes
  • 2 5/16″ Demco Coupler (18,000#) w/ 7k Drop Leg Jack
  • 7 Way Electrical Plug
  • Framed For Roof Vent
  • .024″ Screwless Exterior Aluminum (White or Black at No Additional Charge)
  • (1) Pair Plastic Sidewall Flo-Thru Vents
  • Seamless Aluminum Roof
  • Flat Top Roof w/ 5′ Slanted Wedge
  • 3″ Heavy Duty Flat Top & Bottom Trim
  • ATP Fenders
  • 16″ ATP Stoneguard
  • 3/4″ Drymax Floor
  • 24″ 3/8 Drymax Kickboard (no interior wall board)
  • 24W x 68H Side Door w/Barlock on 7×17 TA (Only)
  • 36W x 68H Side Door w/Barlock on 7 Wide Models
  • 48W x 68H Side Door w/Barlock on 8.5 Wide Models
  • Aluminum Door Holdback
  • Front (C/S) Ramp Door w/ Spring Assist (No Ramp Flaps)
  • Rear Ramp Door w/ Spring Assist (No Ramp Flaps)
  • Stainless Steel Door Hardware
  • 48″ Beavertail on 8.5x
  • (9) 1200# Rope Ties in Floor (Surface Mount)
  • (2) 12 Volt LED Dome Light w/Switch
  • LED Marker Lights
  • LED Strip Tail Lights
  • DOT/CSA Approved Safety Equipment
  • Limited 3 Year Structural Warranty

NOTE: Stealth Enterprises, LLC reserves the right to make changes to product offerings without notice or obligation. Standard equipment, options, specifications, materials, and other items listed on websites and printed materials are accurate at time of publication. Some photographs may show optional items available at additional cost. Some specifications listed may be estimates. Consult your local authorized Stealth Trailer dealer for the most updated models, specifications and pricing.
